PillSleepTracker Pro

Designed to sit on your desktop like Microsoft Sticky Notes -- compact, always-on-top.

Features

Dashboard (Home)

• Time-of-day greeting with today's date
• At-a-glance stat cards: Today's Meds, Last Sleep, Pill Streak
• Quick Take grid: one-click pill logging with undo, colour-coded by medication
• Sleep summary card with score badge and streak counter
• Low stock alerts for medications running low

Medications

• Full CRUD: add, edit, delete medications
• Fields: Name, Dosage, Frequency, Time of Day, Colour Tag, Supply Count, Low Stock Warning, Notes
• 10 colour options for visual differentiation
• Supply tracking with automatic decrement on take
• Active/Inactive toggle for pausing medications
• One-click Take/Undo from both Dashboard and Meds page

Sleep Tracker

• Quick Log presets: 5h, 6h, 7h, 8h, 9h buttons (ending now)
• Manual entry: date, bedtime, wake time, quality slider
• Sleep quality scale: 1-5 (Terrible to Excellent)
• Sleep Factors checkboxes: Caffeine, Alcohol, Exercise, Screen Time, Stress, Nap, Late Meal, Medication
• Notes field for each entry
• Sleep Score (0-100) calculated from duration, quality, and bedtime consistency
• Recent entries list with colour-coded quality and score

Analytics (Stats)

• Summary stat cards: Avg Sleep, Avg Quality, Adherence %, Avg Score
• Time range selector: 7 / 14 / 30 days
• Medication Adherence bar chart (green/amber/red by completion %)
• Sleep Duration line chart with area fill and 7-9h optimal zone
• Sleep Quality & Score dual overlay (scatter + line)
• Sleep Factor Frequency horizontal bar chart (colour-coded beneficial vs harmful)

Settings

• Window opacity slider (30-100%)
• Always-on-top toggle
• Export data as JSON backup
• Export pill log as CSV
• Import data from JSON (supports v1 format migration)
• Open data folder shortcut
• Reset all data (danger zone)

Widget Behaviour

• Always-on-top floating window with pin toggle
• Draggable custom title bar
• Remembers window position, size, opacity, and last active page
• System tray icon with show/quit menu (Windows)
• Auto-saves settings every 30 seconds
• Toast notifications for actions (taken, undone, logged, etc.)
• Sidebar navigation with live clock

Requirements

• Python 3.8+ (3.10+ recommended)
• Windows 10/11 (also works on Linux/macOS)

All Python packages are auto-installed on first launch.

Quick Start

Option A: Batch File (Recommended)

Double-click:  Launch-PillSleepTracker.bat

Option B: PowerShell

.\Launch-PillSleepTracker.ps1

Option C: Direct

pip install customtkinter matplotlib Pillow pystray
python PillSleepTracker.py

Data Storage

Linux/macOS: ~/PillSleepTracker/

Architecture

PillSleepTrackerPro (CTk main window)
  +-- Custom title bar (drag, pin, minimize, close)
  +-- Sidebar (navigation + clock)
  +-- Content area (page switching)
       +-- DashboardPage (stat cards, quick take, sleep summary, alerts)
       +-- MedicationsPage (CRUD list with take/undo)
       +-- SleepPage (quick log, manual entry, history)
       +-- AnalyticsPage (4 matplotlib charts + summary stats)
       +-- SettingsPage (appearance, data management, about)
  +-- ToastManager (overlay notifications)
  +-- DataManager (JSON persistence, query helpers, scoring)

Design Tokens

The app uses a centralised theme class T with GitHub-Dark inspired colours:

Sleep Score Algorithm

The sleep score (0-100) is a composite of three factors:

• Duration (0-40 pts): Gaussian curve centred on 8 hours (480 min) with sigma of 90 min. Sleeping exactly 8 hours scores maximum points; deviations reduce the score smoothly.
• Quality (0-40 pts): Subjective rating multiplied by 8. An "Excellent" (5) rating gives the full 40 points.
• Consistency (0-20 pts): Calculated from the standard deviation of your bedtimes over the past 7 nights. Lower variance (more consistent bedtime) gives higher points.

Customisation Ideas

• Edit the T class to change any colour across the entire app
• Modify PILL_COLOURS to add custom medication colour options
• Adjust SLEEP_FACTORS list to add/remove factors relevant to you
• Change the sleep score weights in calc_sleep_score() to match your priorities

Migration from v1

If you have data from the original PillSleepTracker (v1), use Settings > Import Data. The importer automatically handles:

• Renaming pills to medications and adding UUIDs
• Renaming pill_log to med_log with proper field mapping
• Preserving all sleep_log entries

License

MIT
