OpenNetLimit

OpenNetLimit

Open-source per-application bandwidth limiter and network monitor for Windows.

A free alternative to NetLimiter, built on WinDivert.

Features

• Per-application bandwidth limiting — set download/upload speed limits on any process
• Real-time traffic monitoring — live per-process bandwidth display with scrolling chart
• Connection blocking — block network access for specific applications
• Traffic statistics — SQLite-backed hourly/daily usage tracking with historical queries
• Quota management — daily/weekly/monthly data caps with auto-throttle or auto-block
• Bandwidth usage alerts — threshold rules with cooldowns and tray notifications
• Rule scheduling — time-of-day and day-of-week recurring schedules
• Wildcard rules — match processes by path patterns (*\chrome.exe)
• Bandwidth priorities — high/normal/low priority levels per application
• Import/export rules — share rule sets between machines
• System tray — minimize to tray, quick access context menu
• Theme support — persisted dark/light UI toggle from the status bar
• Localization — persisted UI language toggle with English and Spanish catalogs
• Connection logging — rolling log of established, closed, and blocked connections
• Windows service detection — identifies svchost-hosted service names
• UWP/Store app detection — identifies AppX package names
• Secure IPC — ACL-protected named pipe, admin required for rule changes
• REST API / remote administration — localhost API by default, optional keyed remote bind
• VirusTotal process verification — optional hash-only executable reputation checks
• Geographic IP lookup — optional cached remote IP country/city lookup
• Plugin webhooks — optional manifest-based event plugins without in-process code loading

Requirements

• Windows 10 or later (x64)
• .NET 8.0 Runtime
• Administrator privileges (required for WinDivert driver)

WinDivert Driver

OpenNetLimit uses the WinDivert user-mode packet capture library. The native binaries (WinDivert.dll and WinDivert64.sys) are included automatically via the Native.WinDivert NuGet package.

Important notes:

• The WinDivert driver (WinDivert64.sys) is a signed kernel driver that loads on first use and requires administrator privileges.
• Some enterprise security tools (EDR/AV) may flag or block the WinDivert driver. If you encounter driver load failures, check your security software's block list.
• Hypervisor-Protected Code Integrity (HVCI) may prevent the driver from loading on some systems. See LOLDrivers entry for details.
• WinDivert is licensed under LGPL-3.0 / GPL-2.0. See THIRD-PARTY-NOTICES.txt.

Enterprise Deployment (WDAC/EDR)

WinDivert's signed driver is tracked by LOLDrivers as a dual-use driver and may trigger alerts in enterprise EDR products (CrowdStrike, Defender for Endpoint, etc.). The SigmaHQ detection rule driver_load_win_windivert fires at HIGH severity on driver load. This is expected for legitimate bandwidth management use — WinDivert is not malware but has been used by adversary tooling in the past.

Bundled binary hashes (WinDivert 2.2.2 via Native.WinDivert NuGet):

WDAC allowlist policy (Windows Defender Application Control):

To allow WinDivert on WDAC-enforced systems, add the file hashes to your supplemental policy:

<FileRules>
  <Allow ID="ID_ALLOW_WINDIVERT_DLL" FriendlyName="WinDivert.dll"
         Hash="C1E060EE19444A259B2162F8AF0F3FE8C4428A1C6F694DCE20DE194AC8D7D9A2" />
  <Allow ID="ID_ALLOW_WINDIVERT_SYS" FriendlyName="WinDivert64.sys"
         Hash="8DA085332782708D8767BCACE5327A6EC7283C17CFB85E40B03CD2323A90DDC2" />
</FileRules>

EDR allowlist steps (common products):

• Microsoft Defender for Endpoint: Add WinDivert64.sys path or hash to Indicators > Allow in the Defender Security Center.
• CrowdStrike Falcon: Create a Machine Learning exclusion for the WinDivert64.sys hash or path under IOC Management.
• SentinelOne: Add the WinDivert file hashes to the Exclusions > Hashes allowlist in the management console.
• Carbon Black: Add a bypass rule for the WinDivert driver hash in the Reputation tab.

Verify hashes match the values above before adding allowlist entries. If you build WinDivert from source or use a different version, recompute hashes with certutil -hashfile WinDivert64.sys SHA256.

Getting Started

Building

dotnet restore
dotnet build
dotnet test

Running the Service

The service must run as Administrator to load the WinDivert driver:

dotnet run --project src/OpenNetLimit.Service

Running the UI

In a separate terminal (does not require admin for monitoring):

dotnet run --project src/OpenNetLimit.UI

The UI will auto-connect to the service and display live traffic data. On first launch, a setup wizard guides you through requirements. Use the status-bar theme and language buttons to switch dark/light mode and English/Spanish text. Set OPENNETLIMIT_UI_CULTURE to override the startup UI culture.

Setting Bandwidth Limits

1. Right-click a process in the traffic list
2. Select Set Bandwidth Limit...
3. Enter download/upload limits in KB/s
4. The limit takes effect immediately via the background service

Troubleshooting

• Service won't start: Ensure you're running as Administrator. Check %ProgramData%\OpenNetLimit\last-error.txt for details.
• UI shows "Disconnected": The background service isn't running. Start it first.
• Driver blocked by AV/EDR: Add WinDivert64.sys to your security software's allow list.
• HVCI preventing driver load: WinDivert may be blocked on systems with Hypervisor-Protected Code Integrity enabled.
• REST API mutation returns 403: Set OPENNETLIMIT_API_KEY and send it with X-OpenNetLimit-Key.
• Remote API does not listen on LAN: Set both OPENNETLIMIT_ENABLE_REMOTE_API=1 and OPENNETLIMIT_API_KEY, then provide a non-loopback OPENNETLIMIT_API_URLS prefix.
• Process verification says NotConfigured: Set OPENNETLIMIT_VIRUSTOTAL_API_KEY. OpenNetLimit sends only SHA-256 hashes to VirusTotal; it does not upload files.
• GeoIP lookup says Disabled: Set OPENNETLIMIT_GEOIP_ENABLED=1. Public remote IPs are sent to the configured GeoIP provider and cached; private, loopback, link-local, and multicast addresses are not queried.

Architecture

• OpenNetLimit.Core — Shared models, interfaces, IPC protocol definitions
• OpenNetLimit.Engine — WinDivert packet interception, flow tracking, token bucket rate limiting, packet scheduling
• OpenNetLimit.Service — Windows background service, rule engine, traffic statistics (SQLite), quota management
• OpenNetLimit.UI — WPF desktop GUI with LiveCharts2 real-time charts
• OpenNetLimit.Tests — xUnit unit tests

Data Storage

All persistent data is stored in %ProgramData%\OpenNetLimit\:

IPC Protocol

The UI communicates with the service via a named pipe (OpenNetLimit). Commands:

REST API

The service also exposes a small REST API for local automation and optional remote administration. By default it listens only on http://127.0.0.1:47719/.

Remote administration is intentionally fail-closed: non-loopback prefixes are ignored unless both OPENNETLIMIT_ENABLE_REMOTE_API=1 and OPENNETLIMIT_API_KEY are configured.

Plugin Manifests

Plugins are declarative JSON webhook manifests. OpenNetLimit does not load plugin DLLs or scripts in-process.

{
  "id": "alert-hook",
  "name": "Alert Hook",
  "version": "1.0.0",
  "enabled": true,
  "eventSubscriptions": ["alert.triggered", "quota.warning", "quota.exceeded"],
  "webhookUrl": "https://example.test/opennetlimit"
}

License

MIT — see LICENSE.

WinDivert is licensed separately under LGPL-3.0 / GPL-2.0 — see THIRD-PARTY-NOTICES.txt.
