Vertigo

Vertical video studio for short-form creators.

From the Latin vertere, to turn. Turns raw footage of any shape into polished 9:16 for YouTube Shorts, TikTok, and Instagram Reels.

Features

• Premium PyQt6 UI — polished System / Mocha / Graphite / Latte themes, frameless custom titlebar, calm editor surfaces, refined focus states, accessible controls.
• Four reframe modes:
  • Center Crop — static center column, zero analysis.
  • Smart Track — MediaPipe face detection; viewport pans to follow subjects with smoothed, scene-aware keyframes that never cross a hard cut.
  • Blur Letterbox — full source frame on a softly blurred backdrop.
  • Manual — drag the viewport on the live preview to lock any column.
• Platform presets — YouTube Shorts, TikTok, Instagram Reels, Square (1:1). One click switches output geometry and encoder target bitrate.
• Batch queue — drop many clips at once, preview any one, then Export All to a folder. Per-item status indicator.
• Trim timeline — dual-thumb in/out range slider directly on the preview. Exports respect the trim window via FFmpeg -ss / -t.
• Four one-click trim helpers — Suggest segments (TextTiling-ranked candidates on clips > 10 min, now with min / target / max length sliders; requires AI captions to be generated first so the segmenter has a transcript to work with), Find highlights (energy-ranked moments, Lighthouse + fallback), Trim silences (longest speech-contiguous sections via auto-editor), Tighten to speech (outer speech edges via Silero VAD). Each pops a menu of candidates; picking one drops the trim handles in place.
• Export thumbnails — one-click save of six representative PNG cover frames (Katna-ranked when installed, evenly-spaced cv2 frames otherwise).
• Adjustments panel — live brightness / contrast / saturation sliders; applied via FFmpeg eq= filter appended to the reframe chain.
• Scene detection — PySceneDetect (with a histogram-delta fallback) segments the timeline to stabilize Smart Track.
• Hardware encoding — auto-detects NVIDIA NVENC, Intel QuickSync, AMD AMF, Apple VideoToolbox, and the libx264/libx265 CPU encoders. Pick one in the Output tab, drive a single quality slider, tune the speed preset.
• AI captions — optional faster-whisper transcription (opt-in lazy install) with SRT burn-in. Word-wrapped, mobile-safe styling baked directly into the exported pixels.
• Text overlays — title cards, top straps, lower-thirds, and bottom captions. Per-overlay time range, color, and font size. Preset library for common Shorts/Reels motifs. All burned into the output via drawtext= filter chain.
• Live crop viewport overlaid on the preview player so you see the target frame before rendering.
• Async FFmpeg encoding with real-time progress bar and a scrolling log panel.
• Turnkey bootstrap — single-command launch, auto-installs missing Python deps on first run.
• Binary builds — pyinstaller --clean vertigo.spec produces single-file Windows, macOS .app, and Linux exes. GitHub Actions workflow builds all three on every tag push (or workflow_dispatch) and uploads to a draft release via gh release upload --clobber.

Optional integrations

Each module under core/ below is usable on its own and ships with a clean fallback when the heavy dependency is absent. Install only what you need:

pip install -r requirements-optional.txt   # everything, or
pip install silero-vad                     # cherry-pick

Licensing note. Vertigo itself is MIT. The opt-in deps carry their own licenses (see requirements-optional.txt for per-package detail). Two surfaces deserve calling out:

• boxmot is AGPL-3.0. Desktop builds are fine — Vertigo never bundles boxmot, so installing it on your own machine is your own decision. If you redistribute Vertigo as a hosted / SaaS product alongside boxmot, AGPL-3.0 network copyleft kicks in.
• pyannote.audio model weights are often CC-BY-NC-4.0 (non-commercial) on HuggingFace. The Python code is MIT, but the default diarization checkpoint requires you to accept the HF model card's terms before use.

Install

git clone https://github.com/SysAdminDoc/Vertigo.git
cd Vertigo
python vertigo.py

First run bootstraps PyQt6, OpenCV, NumPy, Pillow, MediaPipe, and PySceneDetect. You must also have FFmpeg on PATH:

# Windows
winget install Gyan.FFmpeg
# macOS
brew install ffmpeg
# Linux (Debian/Ubuntu)
sudo apt install ffmpeg

Use

1. Launch python vertigo.py.
2. Drop a video on the preview area (or click to browse).
3. Pick a platform preset (Shorts / TikTok / Reels / Square).
4. Pick a reframe mode. For Smart Track, MediaPipe scans the clip and returns tracking keyframes.
5. Click Export Vertical and choose an output path. Progress streams in the log panel.

Architecture

vertigo.py                entry + dependency bootstrap + PyInstaller freeze-support
vertigo.spec              PyInstaller build spec (single-file, per-OS icon)
.github/workflows/build.yml  Multi-OS CI + GitHub Release upload
pytest.ini                pytest-qt binding pin (PyQt6)
core/
  _lazy.py                shared pip-install helper with frozen-build guard + threading.Lock
  caption_types.py        Caption + Word dataclasses (lifted from subtitles for clean imports)
  crashlog.py             persistent breadcrumb log — survives frozen-build stderr drop
  probe.py                ffprobe wrapper (VideoInfo dataclass)
  presets.py              platform output presets (Shorts/TikTok/Reels/Square)
  detect.py               MediaPipe face tracker (Haar fallback)
  cameraman.py            SmoothedCameraman + SpeakerTracker (Smart Track smoothing)
  scenes.py               scene detection (PySceneDetect + histogram fallback)
  cluster_track.py        RetargetVid temporal-persistence filter (pure numpy)
  encoders.py             hardware encoder detection (NVENC/QSV/AMF/VT + CPU)
  subtitles.py            faster-whisper wrapper (lazy install) + SRT/ASS writers + karaoke
  caption_styles.py       CaptionPreset dataclass + six bundled looks + style_for_height
  caption_layout.py       face-aware caption alignment heuristic ({\an8} overrides)
  face_samples.py         face sampler used by caption_layout (2 fps MediaPipe)
  overlays.py             TextOverlay dataclass + drawtext filter chain
  reframe.py              FFmpeg filter graph per mode + Adjustments dataclass
  encode.py               FFmpeg subprocess + progress parsing + trim + burn-in
  preflight.py            pre-export sanity checks (codec, duration, free disk)
  dryrun.py               plan-only report (TRACK / LETTERBOX / CENTER strategy)
  hook_score.py           0-100 first-3-second engagement score (no torch)
  segment_proposals.py    T3b — local TextTiling segmenter + silence-gap + length-fit ranker
  animated_captions.py    pycaps post-encode composite (opt-in, Apache-2.0)
  auto_edit.py            auto-editor CLI interop for silence-cut planning
  vad.py                  Silero VAD (opt-in, ONNX, no PyTorch)
  tracker_boxmot.py       BoT-SORT / ByteTrack / DeepOCSORT (opt-in, AGPL-3.0)
  highlights.py           Lighthouse moment retrieval + sliding-window fallback
  diarize.py              pyannote speaker diarization (opt-in, HF token required)
  broll.py                transcript -> keywords -> Pexels -> CLIP b-roll planner
  keyframes.py            Katna-ranked thumbnails (opt-in) + cv2 fallback
ui/
  theme.py                semantic theme tokens + QSS stylesheet generation
  tokens.py               palette / typography tokens consumed by theme.py
  titlebar.py             frameless draggable titlebar + theme picker + brand mark
  assets.py               bundle-aware asset resolver (source + PyInstaller)
  widgets.py              GlassPanel, ModeCard, Toast, FadingTabWidget
  mode_icons.py           painted ReframeMode card icons
  file_drop.py            multi-file drag-drop import zone
  file_dialogs.py         open/save dialog helpers with preset memory
  range_slider.py         dual-thumb trim slider + playhead + shot-boundary ticks
  video_player.py         QMediaPlayer preview + crop-viewport overlay + trim row buttons
  batch_queue.py          queue panel with per-item status + entry_removed signal
  adjustments_panel.py    brightness / contrast / saturation sliders
  output_panel.py         encoder / quality / speed controls
  subtitles_panel.py      AI caption generation + burn-in toggle + animated-style picker
  overlays_panel.py       text-overlay editor (titles / lower-thirds)
  panels.py               shared panel-builder helpers
  main_window.py          composition + wiring + batch driver
  main_controller.py      worker orchestration + export finaliser + segments gate
workers/
  detect_worker.py        QThread: runs FaceTracker
  encode_worker.py        QThread: runs encode.run() + partial-output unlink on cancel
  subtitle_worker.py      QThread: runs faster-whisper transcription
  scene_worker.py         QThread: background scene detection on clip load
  vad_worker.py           QThread: runs Silero VAD for "tighten to speech"
  highlights_worker.py    QThread: runs core.highlights.score_spans
  auto_edit_worker.py     QThread: runs auto-editor CLI for "trim silences"
  pycaps_worker.py        QThread: runs core.animated_captions post-encode composite
  segment_proposals_worker.py  QThread: runs core.segment_proposals.propose_segments
assets/
  icon.svg / icon.png / icon.ico + size variants (16/32/48/128/256/512)
  wordmark.svg           typography-focused brand wordmark
  build_icons.py         procedural Pillow renderer (SVG + PNG + ICO)
  runtime_hook_mp.py     PyInstaller fork-bomb guard (freeze_support)
  logo_prompts.md        5 AI image prompts for high-end brand generation

Reframe strategy reference

Test

python -m pytest -q

pytest.ini pins pytest-qt to PyQt6 so local environments that also have PySide6 installed still exercise the shipped widget stack.

Build binaries

pip install pyinstaller
pyinstaller --clean vertigo.spec
# dist/Vertigo.exe   (Windows)
# dist/Vertigo.app   (macOS)
# dist/Vertigo       (Linux)

Or push a tag and let CI build all three — see .github/workflows/build.yml. A workflow_dispatch run with a tag input lands three artifacts on a draft release.

Requirements

• Python 3.10+
• FFmpeg / ffprobe on PATH
• PyQt6, OpenCV, MediaPipe, NumPy, Pillow, PySceneDetect (auto-installed)

License

MIT — see LICENSE.
