pfBlockerNG Manager v3.5

Comprehensive PowerShell GUI for managing pfBlockerNG on pfSense firewalls.

What's New in v3.5

Fixed Whitelist/Blocklist

• Now properly integrates with pfBlockerNG's configuration system
• Uses pfBlockerNG's PHP API for reliable list management
• Instant effect via Unbound + persistent config.xml storage
• Properly adds to DNSBL suppression list (whitelist) and custom blocklist

Live Monitor Tab (Now First/Default)

• Added whitelist/blocklist buttons for quick actions
• Added VirusTotal lookup button
• Added Copy Domain/IP buttons
• Shows DNS blocked, DNS allowed, AND IP blocks in real-time

New IP Blocking Tab

• View pfBlockerNG IP block logs
• Statistics: total blocks, inbound, outbound, active tables
• Export IP logs to CSV
• AbuseIPDB lookup integration

Settings Panel

• Click "Settings" button in header
• Show/hide individual tabs
• Toggle auto-refresh on tab change
• Configure Live Monitor max entries
• Theme selection (Dark/Light)

Auto-Refresh on Tab Change

• Data automatically refreshes when switching tabs
• Can be disabled in Settings

Tab Overview

Whitelist/Blocklist - How It Works Now

The whitelist and blocklist functions now properly integrate with pfBlockerNG:

Whitelist (DNSBL Suppression):

• Domains added to pfBlockerNG's suppression list in config.xml
• Immediately removed from Unbound DNSBL
• Persists through DNSBL reloads
• Format: .example.com for wildcard, example.com for exact

Blocklist (Custom Block):

• Domains added to pfBlockerNG's custom blocklist
• Immediately added to Unbound as always_nxdomain
• Persists through DNSBL reloads

Requirements

Windows

• Windows 10/11
• PowerShell 5.1+
• Posh-SSH module (auto-installs)

pfSense

1. SSH enabled (System > Advanced > Admin Access)
2. pfBlockerNG-devel installed
3. DNSBL enabled with Unbound mode
4. DNS Reply Logging enabled (for allowed queries)

Installation

1. Download pfBlockerNG-Manager.ps1 and Launch-Manager.bat
2. Double-click Launch-Manager.bat
3. If prompted, allow Posh-SSH installation

Quick Start

1. Enter pfSense IP, port (22), username, password
2. Check "Save" to remember credentials
3. Click Connect
4. Live Monitor starts as default tab
5. Click "Start Streaming" to watch real-time events

Settings

Click the Settings button to customize:

• Theme: Dark or Light
• Visible Tabs: Show/hide any tab
• Auto-refresh on tab change: Enable/disable
• Live Monitor max entries: Default 500

Keyboard Shortcuts (in Live Monitor)

• Select an entry, then click:
  • + Whitelist - Add domain to whitelist
  • + Blocklist - Add domain to blocklist
  • VirusTotal - Open VirusTotal lookup
  • Copy Domain - Copy domain to clipboard
  • Copy IP - Copy IP to clipboard

File Locations

Windows:

%APPDATA%\pfBlockerNG-Manager\
  config.json    - Saved credentials (encrypted)
  settings.json  - App settings
  alerts.json    - Alert rules

pfSense:

/var/log/pfblockerng/dnsbl.log      - DNS blocked queries
/var/log/pfblockerng/dns_reply.log  - DNS allowed queries
/var/log/pfblockerng/ip_block.log   - IP block events

Troubleshooting

Whitelist/Blocklist Not Working

1. Ensure pfBlockerNG-devel is installed (not the regular version)
2. Ensure DNSBL is enabled and in Unbound mode
3. After adding entries, click "Reload DNSBL" in System tab
4. Check that domains appear in List Editor tab after refresh

No DNS Reply Logs

1. In pfSense: Firewall > pfBlockerNG > DNSBL
2. Enable "DNS Reply Logging"
3. Set DNSBL Mode to "Unbound python mode"
4. Save and reload DNSBL

IP Block Tab Empty

1. Ensure pfBlockerNG IP blocking is enabled
2. Check that IP feeds are configured and active
3. IP blocks may be less frequent than DNS blocks

License

MIT License - Free to use and modify.
