CallShield

Open-source spam call and text blocker for Android
15+ layer detection + Gradient-Boosted Tree ML | 32,933 spam numbers | Real-time caller ID | RCS filter | No required API keys

CallShield blocks spam calls and texts using a 15+ layer on-device detection engine with a gradient-boosted tree ML scorer, campaign burst detection, RCS notification filter, and real-time caller ID overlay. Powered by a 32,933-number database with scheduled hot-list updates. Community-maintained, no accounts, no tracking.

v1.7.12 Highlights

• Durable blocked-call logging - blocked-call decisions now enqueue an idempotent pending Room row before responding to Android, then a Hilt-backed retry worker flushes the row into the final call log without duplicating notifications or widget refreshes.

• Room v10 migration - call_log now carries a nullable unique logKey, pending_blocked_call_logs persists retry state, and migration/DAO tests cover duplicate suppression and retry windows.

• Community-report abuse backoff - the Cloudflare Worker rate-limit and dedup helpers now have local tests, and the Android client surfaces HTTP 429 with the server-provided retry delay.

• ASCII-only digit utility - security-sensitive phone-number extraction and UI entry/review paths now share named ASCII-only helpers instead of Unicode digit matching.

• External blocklist subscription guardrails - custom HTTP(S) CSV/TXT/JSON feeds validate byte and row limits, preview add/remove/source impact before commit, and can be disabled or removed with feed-owned rows rolled back.

• Compose BOM 2026.05.00 refresh — UI dependencies now resolve on the current Compose 1.11.1 release train, with Material 3 1.4.0 and refreshed lifecycle/core/savedstate transitive locks across debug, release, and unit test configurations.

• Configuration-aware Compose copy — snackbar, toast, semantic, validation, and search-result count text now use Compose resource APIs instead of stale LocalContext.getString / resources reads inside composables.

• WorkManager 2.11.2 refresh — background sync, hot-list refresh, and daily digest jobs now run on the current WorkManager line with Android 15+ network-constraint fixes.

• Worker schedule contract tests — sync, manual refresh, hot-list, and digest WorkRequests now have JVM coverage for repeat intervals, network constraints, initial delay, and retry backoff.

• DataStore privacy hardening — settings now run on DataStore 1.2.1, and the optional AbstractAPI enrichment key is stored in a private no-backup DataStore instead of the backed-up public settings file.

• Safer backup boundary — database and public preferences remain restorable for device transfers, while optional local credentials migrate out of Android Auto Backup scope on first read or save.

• Reproducible-build groundwork — Gradle dependency locking is enabled, the resolved dependency graph is checked in, AGP VCS metadata is disabled for release APKs, and local release guards block wall-clock build metadata from being embedded into APK inputs.

• Release hash sidecars — release builds now produce SHA256 sidecars for APK artifact integrity, with Windows helpers for signed local releases and content-level APK rebuild comparisons.

• Network hardening — OkHttp is upgraded to 5.3.2 and all direct data, community-report, URL-safety, and caller-ID enrichment hosts are protected by centralized certificate pinning.

• Modern Android build stack — AGP is upgraded to 8.10.1, Kotlin/KSP are aligned on 2.2.21, and Room is upgraded to 2.8.4, keeping codegen and R8 compatible with the current Kotlin metadata used by the networking stack.

• Stats and scan feedback polish — weekly activity labels now respect locale weekday names, Statistics detection-source labels are resource-backed, and scan permission/failure copy is consistent across call-log and SMS flows.

• Settings credential polish — the optional AbstractAPI key is masked by default, has explicit show/hide control, reports "Not configured", "Saved locally", and "Unsaved changes" states before saving, and is now kept out of backed-up public preferences.

• Premium-polish UX refresh — shared premium action, compact-action, icon-tile, and state-card treatments now unify dashboard, lookup, details, recent-call, blocklist, diagnostics, onboarding, and settings flows.

• Clearer recovery states — Blocked Log empty and filtered states now explain what happened and provide a direct "Show all activity" recovery action when filters hide records.

• Trust-focused settings feedback — the trusted push-alert source picker now shows installed-source coverage and skeleton loading while package labels resolve.

• Hardening foundation from v1.7.2 — spoof-proof ASCII phone normalization, SMS size caps, regex ReDoS validation, LRU notice gates, separated PendingIntent IDs, and atomic crash-log writes.

• STIR/SHAKEN Authenticated Allow — carrier-authenticated caller ID can short-circuit weak heuristic / ML blocks while still yielding to every explicit user and system rule.

• Answered-caller trust — numbers answered repeatedly inside the configured lookback window can ring through lower-confidence heuristic/ML suspicion while explicit block rules still win first.

• Emergency callback grace — unknown callbacks can ring through after a local emergency call for a configurable window while explicit block rules still win first.

• SMS burst protection - repeated unknown SMS senders or same-prefix floods can be blocked as sms_burst, with blocked-SMS notification actions to mark safe or report.

• 711 total JVM unit tests - the local unit suite covers detection, workers, utilities, repository contracts, and permission readiness before release.

• Gradient-Boosted Tree ML model — 20 features, pure Kotlin, no TFLite dependency.

• Campaign burst detection — NPA-NXX prefix clustering identifies coordinated spam waves.

• Full accessibility — content descriptions across Compose UI, 48dp minimum touch targets.

How It Works

1. 32,933 confirmed spam numbers — sourced from 1.75M FCC consumer complaints (2+ reports each), FTC Do Not Call, ToastedSpam, and community reports
2. 15+ layer detection + ML — database, heuristics, campaign burst detection, on-device gradient-boosted tree, SMS content/burst analysis, RCS filter, STIR/SHAKEN, and more
3. Real-time caller ID overlay — parallel lookups against SkipCalls, PhoneBlock, WhoCalledMe + OpenCNAM caller name, with SIT tone anti-autodialer
4. Scheduled hot list — trending spam numbers and campaign ranges refresh through the repository data pipeline
5. Callback-aware — won't block callbacks from numbers you recently called, answered repeatedly, after a local emergency call, or urgent repeated callers
6. Community-driven — one-tap anonymous contribution via Cloudflare Worker, daily merge into database

Detection Pipeline (v1.7.12)

All detection layers implement a shared IChecker interface and run in priority order via CheckerPipeline.run — first non-null result wins, every layer is testable in isolation. Priorities are stable numbers; the ladder below is the live order.

SMS-specific layers (append after the shared chain): SMS Context Trust → SMS Keyword Rules (with schedule) → SMS Burst Protection → SMS Content Analysis (30+ regex patterns, URL shorteners, suspicious TLDs, spam domain blocklist).

Additional Layers

• Caller ID Overlay — suspicious calls (heuristic score 30-59) trigger a live multi-source lookup overlay with SkipCalls, PhoneBlock, WhoCalledMe + OpenCNAM caller name
• RCS Filter — NotificationListenerService monitors Google/Samsung Messages for RCS spam
• URL Safety — local spam-domain checks run before URLhaus (abuse.ch), with query-string stripping enabled by default for remote SMS/RCS URL checks
• STIR/SHAKEN — blocks calls failing carrier caller ID verification (Android 11+)
• After-Call Feedback — "Was this spam?" notification after suspicious calls for community reporting

Per-Rule Schedules (A7)

Any wildcard, range, or SMS keyword rule can be time-gated to specific days of the week and an hour window. The hour picker supports overnight wrap; daysMask = 0 is the "no gating" sentinel so rules created before v1.6 behave identically.

Live Caller ID Overlay

When a call comes in, CallShield shows a real-time overlay that queries 4 sources simultaneously:

┌──────────────────────────────────┐
│ LIKELY SPAM                      │
│ (212) 555-1234                   │
│ New York, NY                     │
│ Spam Score: 80% (17 reports)     │
│ JOHN DOE (OpenCNAM)             │
│ ⚠ SkipCalls: Flagged            │
│ ⚠ PhoneBlock: 5 reports         │
│ ⚠ WhoCalledMe: 12 reports       │
│ All sources checked              │
│ [Search] [Block] [Dismiss]       │
│ 🔈 Play SIT Tone (anti-dialer)  │
└──────────────────────────────────┘

• Shows instantly with area code, then updates live as each source responds
• OpenCNAM caller name lookup (free, 60 req/hr)
• SIT Tone — ITU-T E.180 three-tone sequence tricks autodialers into removing your number
• Color-coded: green (safe) → yellow → orange → red (spam)

ML Spam Scorer

On-device 20-feature gradient-boosted tree model — pure Kotlin, no TFLite, no heavy ML libraries. Runs in microseconds.

Trained weekly from the CallShield database (50K positive + 50K negative samples). Threshold: 0.7 (conservative).

Features

Number Lookup

• Instant spam check through all 15+ detection layers with animated score gauge (0-100)
• Auto-paste from clipboard, area code lookup (330+ US/CA), haptic feedback
• Multi-source reverse lookup: SkipCalls + PhoneBlock + WhoCalledMe + OpenCNAM

Recent Calls & Blocked Log

• Recent calls with contact names, risk indicators, call type icons, filter chips (All/Missed/Spam)
• Blocked log with swipe-to-dismiss + undo, grouping with severity-scaled accent bars, filter chips
• Staggered entrance animations, shimmer loading skeletons

Rules Management (5 tabs)

• Blocklist, Wildcards, Keywords, Whitelist, Database
• Export/import blocklists as JSON, per-rule enable/disable toggles
• Regex validation before adding wildcard rules

Statistics

• Weekly bar chart with daily breakdown
• Detection source donut chart
• Monthly trend line
• Top offenders, area code heatmap, hourly heatmap

Smart Features

• Smart suggestions — detects area code spam patterns, one-tap block entire area code
• Weekly trend indicator — shows if spam is increasing or decreasing vs last week
• Last blocked preview card on dashboard with tap-to-inspect
• Blocking profiles: Work / Personal / Sleep / Maximum / Off
• Callback detection + repeated urgent caller allow-through
• FTC Do Not Call complaint filing
• After-call "Was this spam?" feedback notification

Home Screen Widget

• Today vs yesterday blocked count with trend indicator
• Last blocked number and time
• Quick-access to lookup and protection status

Community

• One-tap anonymous contribution via Cloudflare Worker
• False positive reporting subtracts votes
• Share spam warnings to any app

Data & System

• Selective backup/restore for rules, non-secret settings, and opt-in logs; CSV log export; auto-cleanup (7/14/30/90 days)
• Weekly full sync + scheduled hot list refresh, daily digest notification
• Quick Settings tile, app shortcuts, home screen widget
• Protection test validates all layers and permissions
• Onboarding wizard with permission requests

Data Sources

Database (32,933 numbers, weekly CI)

Hot List (scheduled refresh)

Real-Time Lookup (overlay only)

URL Safety (post-decision)

Security

• Network security config — cleartext traffic disabled in production
• Signing credentials — stored in local.properties, not hardcoded in build files
• Restricted FileProvider paths — scoped to export directory only
• Scoped backup — database and public settings are backed up for transfer/restore, while the optional AbstractAPI key is migrated to a private no-backup DataStore

Privacy

All detection runs on-device. No personal data is collected. Network requests:

• Syncing spam database from GitHub (public)
• Real-time lookups against free public APIs (number queried, not stored)
• Community reports to Cloudflare Worker (phone number only, no identity)
• URLhaus checks for SMS URL safety after local spam-domain matching; fragments and query strings are stripped by default

No required API keys. The optional AbstractAPI key stays on-device in no-backup storage. No accounts. No analytics. No ads.

Requirements

• Android 10+ (API 29)
• STIR/SHAKEN requires Android 11+ (API 30)
• Caller ID overlay requires "Display over other apps" permission
• RCS filter requires Notification Access permission

Building

./gradlew verifyReproducibleBuildInputs verifyReleaseApkReproducibleMetadata

Requires JDK 17+. Signed APK at app/build/outputs/apk/release/app-release.apk. Generate the release hash sidecar with:

.\scripts\write-release-sha256.ps1

See docs/reproducible-builds.md for the dependency-lock and hash-comparison runbook.

F-Droid submission prep lives in fastlane/metadata/android/en-US/, docs/fdroid/com.sysadmindoc.callshield.yml, and docs/fdroid-submission.md. The actual F-Droid merge request and signature-copy verification still require an fdroiddata/GitLab environment.

Signing: Create local.properties in the project root with your keystore credentials:

RELEASE_STORE_FILE=path/to/keystore.jks
RELEASE_STORE_PASSWORD=...
RELEASE_KEY_ALIAS=...
RELEASE_KEY_PASSWORD=...

Testing

./gradlew testDebugUnitTest   # 711 tests
./gradlew connectedDebugAndroidTest -Pandroid.testInstrumentationRunnerArguments.class=com.sysadmindoc.callshield.platform.TargetSdkBehaviorSmokeTest

Run tests, lint, release metadata checks, and artifact builds locally before publishing.

Tech Stack

For deep technical details, see CLAUDE.md.

License

MIT
